Len Performance Track Shock Front For Ski-Doo Snowmobile Models LS4-80001F OEM 503193283

Description

SHOCK LOCATION: FRONT TRACK
SHOCK WEIGHT (lbs): 5.85
SHOCK LENGTH OPEN: 365mm / 14.4inch
SHOCK LENGTH CLOSED: 251mm / 9.9inch
SHOCK STROKE LENGTH: 114mm / 4.5inch
EYELET TOP INNER DIAMETER: 12.5mm / 0.5inch
EYELET TOP WIDTH: 25.2mm / 1.0inch
EYELET BOTTOM INNER DIAMETER: 10.1mm / 0.4inch
EYELET BOTTOM WIDTH: 29.5mm / 1.2inch
SPRING DIAMETER: 77.4mm / 3.0inch
COMPRESSION ADJUSTMENT High Speed/Low Speed: 5

Len Performance was developed in the heart of the American Midwest by riders that are passionate about the powersports industry and the machines they ride. We set off to develop a line of high performance shocks that we could rely on whether we were on the trails in Minnesota or in the backcountry of Wyoming. We knew what we wanted, a rebuildable reservoir shock that is tunable, adjustable but also user friendly.

Len Snowmobile Ski Shocks feature a user friendly intuitive design and come standard with a 5 click rebound adjustment for increased adaptability to any riders experience level in any condition!
The springs are powder coated to reduce corrosion, increase durability and ensure continued strength. The hardened chromoly shaft increases overall strength and seal longevity. Serviceable design increases the lifespan of our shocks and ensures consistent performance for many years to come.
Annodized aluminum finned reservoir offers added surface area for superior cooling, while also increasing strength. Len Shocks all come standard with a 5 stage compression adjustment. User friendly intuitive design features 5 click compression adjustments for seamless adaptation.
All springed shocks feature a threaded body for ultimate preload adjustability. Anodized dual ring locking adjusters make it easy to adjust your preload but ensure they stay set once you have them adjusted to your preferred settings.

Brand: Len Performance
Part Number: LS4-80001F

Fitment:

• 2016-2018 Ski-Doo MXZ 1200 Blizzard 4-TEC 129 / Front Track
• 2015-2018 Ski-Doo MXZ 1200 TNT 4-TEC 129 / Front Track
• 2016-2018 Ski-Doo MXZ 600 Blizzard HO E-TEC 129 / Front Track
• 2016 Ski-Doo MXZ 600 Blizzard HO E-TEC Front Track
• 2015-2017 Ski-Doo MXZ 600 Sport ACE Front Track
• 2015-2017 Ski-Doo MXZ 600 Sport Carb Front Track
• 2015-2018 Ski-Doo MXZ 600 TNT HO E-TEC 129 / Front Track
• 2019 Ski-Doo MXZ 600R Blizzard E-TEC 129 / Front Track
• 2020 Ski-Doo MXZ 600R E-TEC Front Track
• 2019-2020 Ski-Doo MXZ 600R E-TEC Iron Dog / Front Track
• 2019-2020 Ski-Doo MXZ 600R TNT E-TEC 129 / Front Track
• 2015 Ski-Doo MXZ 800R ETEC IRON DOG / Front Track
• 2016-2017 Ski-Doo MXZ 800R Blizzard E-TEC 129 / Front Track
• 2016 Ski-Doo MXZ 800R Blizzard E-TEC Front Track
• 2015-2017 Ski-Doo MXZ 800R TNT E-TEC Front Track
• 2018-2019 Ski-Doo MXZ 850 Blizzard E-TEC 129 / Front Track
• 2018-2020 Ski-Doo MXZ 850 TNT E-TEC 129 / Front Track
• 2016-2018 Ski-Doo MXZ 900 Blizzard ACE 129 / Front Track
• 2015-2018 Ski-Doo MXZ 900 TNT ACE 129 / Front Track
• 2015-2018 Ski-Doo MXZ X 1200 4-TEC 129 / Front Track
• 2015-2018 Ski-Doo MXZ X 600 HO E-TEC 129 / Front Track
• 2017 Ski-Doo MXZ X 600 HO E-TEC Front Track
• 2018-2022 Ski-Doo MXZ X 600R E-TEC 129 / Front Track
• 2018 Ski-Doo MXZ X 600R E-TEC Iron Dog / Front Track
• 2015-2017 Ski-Doo MXZ X 800R E-TEC 129 / Front Track
• 2017-2022 Ski-Doo MXZ X 850 E-TEC 129 / Front Track
• 2015-2016 Ski-Doo MXZ XRS 600 HO E-TEC 129 / Front Track
• 2016 Ski-Doo MXZ XRS 600 HO E-TEC Front Track
• 2017-2018 Ski-Doo MXZ XRS 600 Iron Dog HO E-TEC 129 / Front Track
• 2015-2018 Ski-Doo MXZ XRS 600 Iron Dog HO E-TEC Front Track
• 2019-2020 Ski-Doo MXZ XRS 600R E-TEC 129 / Front Track
• 2019-2020 Ski-Doo MXZ XRS 600R E-TEC Front Track
• 2015-2017 Ski-Doo MXZ XRS 800R E-TEC 129 / Front Track
• 2018-2020 Ski-Doo MXZ XRS 850 E-TEC 129 / Front Track
